jspsych logo

Introduction to jspsych

Shreshth Saxena

Differences in offline vs. online experiment building

Traditional in-lab experiments:
  • Same hardware-software configuration for all participants
  • Local data storage and transmission
  • Extensive choice of programming languages
Online experiments:
  • Diverse configurations of hardware-software
  • Central data storage through a server
  • Use of web development technologies

So why bother with online experiments?

So why bother with online experiments?


  • Ecological and external validity
    • Participation from diverse home environments
  • Accessiblity
    • Reach rare or specific sub-populations
  • Efficiency
    • Saves time and money for data collection
  • Reproducibility
    • Open web development
but also...

  • High statistical power and better generalizability of findings
  • Reduction of experimenter effects
  • Detectability of motivational confounding
  • Experimenting around the clock
  • Avoidance of organizational problems
  • Accessiblity to research

Web Technologies

Web Technologies


  • HTML - Content
    • Structuring web documents and apps
  • CSS - Appearance
    • Styling web documents and apps
  • JavaScript - Interactivity
    • Web's native programming language

Quick demo

open https://codepen.io/pen/ in your browsers to follow
QR2

Recommended tutorial

https://developer.mozilla.org/en-US/docs/Web/Tutorials
QR1

Tools for online experiments

Tools for online experiments

QR1

Let's Code

Classic HTML tree


							<html>
							  <head>
							    <title>...</title>
							  </head>
							  <body>
							  	<script>
							  	...
							  	</script>
							  </body>
							</html>

Give it a title


							<html>
							  <head>
							    <title>Hello world</title>
							  </head>
							  <body>
							  	<script>
							  	...
							  	</script>
							  </body>
							</html>

import jsPsych


							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							  </head>
							  <body>
							  	<script>
							  	...
							  	</script>
							  </body>
							</html>

Easy stylesheet import


							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							    <link href="https://unpkg.com/jspsych@8.2.0/css/jspsych.css" rel="stylesheet" type="text/css" />
							  </head>
							  <body>
							  	<script>
							  	...
							  	</script>
							  </body>
							</html>

Init jsPsych


							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							    <link href="https://unpkg.com/jspsych@8.2.0/css/jspsych.css" rel="stylesheet" type="text/css" />
							  </head>
							  <body>
							  	<script>
							  		const jsPsych = initJsPsych();
							  	</script>
							  </body>
							</html>

Display stored data


							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							    <link href="https://unpkg.com/jspsych@8.2.0/css/jspsych.css" rel="stylesheet" type="text/css" />
							  </head>
							  <body>
							  	<script>
							  		const jsPsych = initJsPsych({
							  			on_finish: function() {
									        jsPsych.data.displayData('json');
									    }
							  		});
							  	</script>
							  </body>
							</html>

Create a trial



							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							    <link href="https://unpkg.com/jspsych@8.2.0/css/jspsych.css" rel="stylesheet" type="text/css" />
							  </head>
							  <body>
							  	<script>
							  		const jsPsych = initJsPsych({
							  			on_finish: function() {
									        jsPsych.data.displayData('json');
									    }
							  		});

										const hello_trial = {
											type: jsPsychHtmlKeyboardResponse,
											stimulus: 'Hello world!'
										}
							  	</script>
							  </body>
							</html>

Run the experiment


							<html>
							  <head>
							    <title>Hello world</title>
							    <script src="https://unpkg.com/jspsych@8.2.0"></script>
							    <script src="https://unpkg.com/@jspsych/plugin-html-keyboard-response@2.1.0"></script>
							    <link href="https://unpkg.com/jspsych@8.2.0/css/jspsych.css" rel="stylesheet" type="text/css" />
							  </head>
							  <body>
							  	<script>
							  		const jsPsych = initJsPsych({
							  			on_finish: function() {
									        jsPsych.data.displayData('json');
									    }
							  		});

										const hello_trial = {
											type: jsPsychHtmlKeyboardResponse,
											stimulus: 'Hello world!'
										}

								   	jsPsych.run([hello_trial]);
							  	</script>
							  </body>
							</html>
Save the file with an ".html" extension and open in browser
but what if we want to allow only spacebar for response?
Docs are your best friend!
jspsych.org
